Positive Displacement Pumps
3ZB-670/900HP positive displacement pumps are widely used for intermittent oilfield operations like acidizing, fracturing, well killing, and so on. This horizontal reciprocating frac triplex plunger pump is designed in two plunger diameters (4”and 4-1/2”) to fulfill multiple pressures and displacements and they adopt the same power end. In this frac triplex plunger pump, the maximum rated brake power is 670 KW (900 HP), and the stroke is203.2 mm(8”).
|
Pump Type |
900 |
|
Max. Input Power |
670 KW |
|
Max. Load of Conrod |
532000 N |
|
Stroke |
203.2 mm |
|
Max. Specific Water Cycle |
300 rpm |
|
Drive Ratio |
5.619:1 |
|
Dimension |
2012 × 1410 ×1016 mm |
|
Weight |
4082 kg |
|
SpecificWater Circle(rpm) |
100 |
150 |
200 |
250 |
330 |
|||||
|
Plunger Diameter |
Displacement (L/min) |
Pressure (Mpa) |
Displacement (L/min) |
Pressure (Mpa) |
Displacement (L/min) |
Pressure (Mpa) |
Displacement (L/min) |
Pressure (Mpa) |
Displacement (L/min) |
Pressure (Mpa) |
|
3-3/4” |
434 |
72.3 |
652 |
55.5 |
869 |
41.6 |
1086 |
33.3 |
1303 |
27.8 |
|
4” |
494 |
65 |
740 |
48.8 |
988 |
36.6 |
1236 |
29.3 |
1483 |
24.4 |
|
4-1/2” |
625 |
51.7 |
938 |
38.6 |
1251 |
28.9 |
1564 |
23.1 |
1876 |
19.3 |
|
5” |
772 |
41.3 |
1158 |
31.2 |
1544 |
23.4 |
1931 |
18.7 |
2317 |
15.6 |
- 1800HP
Our 1800HP frac pump skid refers to triple plunger pump for oil/gas/petroleum well stimulation. For this horizontal positive-displacement reciprocating pump, the maximum rated brake power is 1342 KW (1800 HP) and the stroke is203.2 mm(8”). Besides, three plunger diameters are optional:4”, 4-1/2”and5”. In this way, it is suitable...
- 2000HP
3ZB-1490/2000HP reciprocating triplex plunger pumps are large-power horizontal pump units whose maximum rated brake power is 1490 KW (2000 HP). This positive-displacement pump is widely used for intermittent oil exploiting operations, such as acidizing, fracturing, well killing, and so on. Its stroke is203.2 mm(8”). And three pl...
